Carrier Access Access Navigator - Manual (Page 105)

C
HAPTER
Electrical Installation
In this Chapter
n Compliance and Safety Requirements ... 6-2
n Static-Sensitive Equipment Handling Procedures ... 6-3
n Tools and Materials Required
... 6-4
n Chassis Ground Connection ... 6-5
n DSX-1 Cable Connections ... 6-8
n RS-232 Management Connection ... 6-17
n Ethernet Management Connection ... 6-22
n External Timing Source (BITS) Connection ... 6-25
n Alarm Output Connections ... 6-27
n Alarm Input Connections
... 6-31
n DC Power Connections ... 6-35
n Dress Cables and Wires ... 6-38
n Acceptance Test ... 6-39
n Install Redundant Controller Card ... 6-49
n Install Additional Quad T1 Framer Cards
... 6-55
n Configure Management Interfaces ... 6-61
