Access Navigator - Release 1.8 August 2003 18-153
CLI Language Reference
CLI Command List
Description:
Show SNMP
Purpose: Displays the current snmp settings. To protect management access, the Community
names can only be viewed and changed by CLI commands.
Simple Network Management Protocol (SNMP) enables network operations centers
(NOCs) to monitor and manage network elements across an internetwork. The Access
Navigator supports SNMP through its Ethernet port. Various set snmp commands are
used to set up the Access Navigator for access by the carrier’s TCP/IP management
network.
Security: Level 3 (monitor)
Syntax: show snmp
Message:
System Name: Acme Corp AN#2
System Location: DNVRCO1A201
System Contact: Site Manager
GET Community: public
SET Community: public
TRAP Community: public
NMS #1: 192.168.0.65
NMS #2:
NMS #3:
Description: System name, location, contact, and communities are text strings. Up to three Network
Management System (NMS) stations can receive trap messages at their IP address.
Item Description
CH Channel numbers in two rows, 1-12 and 13-24.
Span Interface name (span number).
T1#1(1) – T1 interface #1, with up to 24 channels.
T1#2(2) – T1 interface #2, with up to 24 channels.
SDSL(2) – SDSL interface, with up to 16 channels.
FX#1(3) – FX card #1, with up to 12 channels.
FX#2(4) – FX card #2, with up to 12 channels.
V35(5) – V.35 interface, with up to 24 channels.
RS232(6) – RS-232 port, with one channel.
