Access Navigator - Release 1.8
Physical Installation
Attach Access Navigator to Plywood
Figure 5-12. Mounting Hole Pattern on Plywood
18 3/8 inches
6 3/4 inches
3/4 inch
3/4 inch
Mark Screw Locations
for Mounting Brackets
(8 Places)
Access
Navigator
