18-126 August 2003 Access Navigator - Release 1.8
CLI Language Reference
CLI Command List
Set Remote V35 DSU
Purpose: Determines if the Access Bank II V.35 interface will respond to standard V.54 Data
Service Unit (DSU) loopcode patterns for payload loopbacks. When enabled (default
setting), the interface will respond to loopup and loopdown codes. This permits remote
testing of the V.35 data link up to the customer interface.
Security: Level 2 (operator)
Syntax: set remote <n> v35 dsu <off|on>
Example: set remote 9 v35 dsu on
Set Remote V35 RxClock
Purpose: Sets the Access Bank II V.35 interface receive clock source to internal or external.
NOTE:
Internal clock source timing is recommended. This setting prevents
data slips by synchronizing the receive timing to the T1 interface.
Security: Level 2 (operator)
Syntax: set remote <n> v35 rxclk <int|ext>
Example: set remote 9 v35 rxclk int
Set Remote V35 Speed
Purpose: Sets the DS0 data speed to either N
´
56 Kbps (7-bit words) or N
´
64 Kbps (8-bit
words), where N is the number of DS0s assigned to the V.35 interface. The V.35 port
is a synchronous interface, so both the speed and number of DS0s are required to
calculate the clock rate. For example, if four DS0s are assigned, the N
´
56 setting
produces a rate of 224 Kbps. When N
´
56 is selected, the V.35 interface inserts a zero
into the least significant bit of the DS0 octet.
Field Description
n DS1 number, 1 to 32.
off Disables DSU loopcode detection.
on Enables DSU loopcode detection.
Field Description
n DS1 number, 1 to 32.
int Set to internal clock source.
ext Set to external clock source
