Access Navigator - Release 1.8 August 2003 18-117
CLI Language Reference
CLI Command List
Security: Level 2 (operator)
Syntax: set eoc <primary|secondary> <n:ch|none>
Example: set eoc primary 25:12
Example: set eoc secondary 29:12
Example: set eoc primary none
Set Ethernet IP Address
Purpose: Configures Ethernet settings for Telnet and SNMP. If you are not going to use the
Ethernet port, do not make any electrical connections to it. Ethernet functions can only
be provisioned through an RS-232 management session, since you must set up the IP
address. After establishing a Telnet session, you can change the settings.
NOTE: If you change the IP address via Telnet, you will lose the IP
connection. The session will remain in effect for 2 hours while it times out.
Security: Level 2 (operator)
Syntax: set ethernet ip address
Field Description
primary Set location of primary EOC link.
secondary Set location of secondary EOC link.
n DS1 number, 1 to 32, that contains EOC link.
ch DS0 channel, 1 to 24, within DS1.
none Removes EOC channel assignment
Field Description
address Each Access Navigator on the same Ethernet network must have
a unique static Internet Protocol (IP) address. IP addresses have
the format xxx.xxx.xxx.xxx, where each xxx is a decimal
number between 0 and 255. For example, 192.168.0.123 is a
valid IP address. Note that the address contains only three
periods, one between each of the four numbers. If the Ethernet
interface is not used, type
none for the IP address.
