Access Navigator - Release 1.8
August 2003
13-17
Provision Remote Adit 600 via IP DS0
Provision Drop DS1s to Remote Adit
10. Set drop DS1 line buildout (lbo) to required DSX-1 equalization or CSU attenuation
set ds1
Example:
set ds1 1 lbo 1
The setting is a number from 1 to 9, and is defined as follows:
Setting
Definition
1
Set DSX-1 equalization for 0-133 ft.
2
Set DSX-1 equalization for 133-266 ft.
3
Set DSX-1 equalization for 266-399 ft.
4
Set DSX-1 equalization for 399-533 ft.
5
Set DSX-1 equalization for 533-666 ft.
6
Set CSU attenuation for LBO of 0dB.
7
Set CSU attentation for LBO of -7.5dB.
8
Set CSU attenuation for LBO of -15dB.
9
Set CSU attenuation for LBO of -22.5dB.
NOTE:
When loop code detection is turned on, the Access Navigator will respond to
T1.403 ESF bit patterned loop requests. Loop detection is normally turned off for DS1
drops.
11. Set drop DS1 loop request code detection off with the following command:
set ds1
Example:
set ds1 1 loopdetect off
12. Set DS1 identification
set ds1
Example:
set ds1 25 id "DS1#10"
13. Set DS1 in service
set ds1
Example:
set ds1 1 up
