11-24 August 2003 Access Navigator - Release 1.8
Provision Remote Access Bank II
Configure Remote T1 Drop Interface (if used)
Configure Remote T1 Drop Interface (if used)
CAUTION! I F THE T1 D ROP WILL BE USED , THE T1 D ROP CIRCUIT OR LOOPBACK
MUST BE INSTALLED BEFORE DOWNLOADING THE CONFIGURATION , OTHERWISE THE
RESULTING AIS ALARM WILL TAKE DOWN THE FDL COMMUNICATIONS LINK UNTIL THE
CIRCUIT IS INSTALLED AND THE ALARM IS CLEARED .
NOTE:
This is a second T1 connection on the Access Bank II, not the T1 connection
between the Access Navigator and the Access Bank II.
1. Show current remote interface settings with the following command:
show remote
Example: show remote 11
Example: show remote all
The show command will display the remote interface settings the each DS1 specified, or for all
DS1s. For example, the message for showing DS1 number 11 would look similar to the following:
Settings for remote device Remote Device #11:
Remote Config: disabled
T1 Drop Port:
Line Coding: AMI
Framing: D4
Line Build Out: DSX-1 0-133 ft. (or 0 db)
PRM: AT&T
V.35 Port:
CTS: Always High
Rx Timing: Internal
Clock Inversion: None
Data Inversion: Normal
Speed: Nx64
DSU: On
RS232 Port:
Baud Rate: 9,600
Data Bits: 8
Parity: None
Stop Bits: 1
2. If drop T1 Drop settings are correct, skip remaining steps.
