Access Navigator / GR-303 + Data Host
CSA Requirements
CSA Requirements
This telecommunication network equipment conforms with Canadian Standards Association (CSA)
standard C22.2 No. 950.95. To maintain this compliance, all access covers must be replaced after
servicing the equipment to prevent fires from spreading to nearby equipment.
Ordering Information
Part Number Item Description
930-0201 AN/GR-303/R/32 Access Navigator GR-303 + Data Host,
32 T1 Redundant Package:
2 AN-GR-303 Controller Cards
8 AN-Quad T1 Framer Cards
930-0200 AN-Case Access Navigator redundant NEBS chassis and
backplane. Chassis holds two Controller cards
and eight Quad T1 Framer cards (32 T1 circuits).
Order cards separately.
740-0017 AN-GR-303
Controller Card Access Navigator Controller card with GR-303
and DCS software.
740-0018 Quad T1 Framer Card Access Navigator Quad T1 Framer card
terminates 4 T1 interfaces from switch, customer
site, or data network.
005-0025 DSX-1 Cable 64-pin DSX-1 cable, 10 feet long, male/male.
Two cables must be ordered per Access
Navigator, one TX, one RX. May be used for
DS1 and DSX-1 transmission levels.
005-0030 DSX-1 Cable 64-pin DSX-1 cable, 25 feet long (see 005-0025).
710-0153 19”/23” Universal
Mounting Brackets Universal mounting brackets and screws for 19
and 23 inch equipment racks. This bracket set is
included with all Access Navigator unit
purchases.
710-0003 19” Vertical Mount
Crossbars Two heavy-duty 19 inch horizontal crossbars
mount in equipment rack and enable vertical
installation of up to 6 Access Navigator and Wide
Bank 28 products.
710-0004 23” Vertical Mount
Crossbars Two heavy-duty 23 inch horizontal crossbars
mount in equipment rack and enable vertical
installation of up to 6 Access Navigator and Wide
Bank 28 products.
770-0079 AN-Manual Access Navigator User Manual is included with
all Access Navigator unit purchases.
