Access Navigator - Release 1.8 August 2003 10-13
Provision GR-303 Service
Set Unused Circuits Out of Service
NOTE:
Commands containing ds0 require the operator to enter both the DS1
and DS0 channel number or channel range. The DS1 and DS0 numbers are entered with
a colon separating the numbers. For example, the channel list for DS1 #4 and DS0 channel
#8 would be entered as ds0 4:8. The channel list may also contain a range of DS0
channels. For example, DS1 #6 and DS0 channels #1 through #12 would be entered as
ds0 6:1-12
. A colon follows the DS1 number, and the beginning and ending DS0
channels are separated by a hyphen.
6. Display current DS0 status with the following command, where is the DS0 or range of
DS0s in the DS1 to be turned up:
status ds0
Example: status ds0 1:1-4
The status command will display the status for each DS0 specified. For example, the message for
DS1 #1, DS0 channels 1 to 4, and DS1 #32, DS0 channels 1 to 4, would look similar to the
following:
Interface Status
--------- ------
DS1 1 Channel 1 In Service
DS1 1 Channel 2 In Service
DS1 1 Channel 3 In Service
DS1 1 Channel 4 Out of Service
DS1 32 Channel 1 Card Not Installed
DS1 32 Channel 2 Card Not Installed
DS1 32 Channel 3 Card Not Installed
DS1 32 Channel 4 Card Not Installed
7. Verify status of DS0 circuits on DS1 lines to be turned up by comparing DS0 status with office
records. If there is a discrepancy, follow standard practices to resolve problem.
Set Unused Circuits Out of Service
NOTE:
The factory default sets all DS1s and DS0s in-service (up). To prevent
inadvertent service disruptions, it is good practice to set circuits out of service (down) when
not in use or not provisioned in the switch. Set the type of unused DS0 channels to match
the DS0 type configured on the device at the other end of the DS1. If the DS1 is not
terminated, set the type to data.
Set unused circuits out of service with the following commands.
set ds1 down
set ds0 down
set ds0 type <voice|data>
