10-8 August 2003 Access Navigator - Release 1.8
Provision GR-303 Service
Provisioning TR-08 Service with GR-303 Translation
Framing and FDL Settings
SLC-96 uses two types of framing: SLC-96 DLL and SLC-96 S4. The combination of setting for
the framing type and FDL protocol determine which framing type will be used for the drop DS1.
For Shelf A, the DS1 FDL protocol is set to “slc96” to obtain SLC-96 DDL framing with its out-
of-band data link management channel. For Shelf B, C, and D, the FDL is set to “none” to obtain
standard SLC-96 S4 (or D4) framing.
Access Bank I/TR-08 Switch Settings
When installing the Access Bank I/TR-08, Switch 4 (framing) on its front panel is set OFF for Shelf
A, or set ON for Shelf B, C, D. Response to loopback code patterns presented over the DS1 (T1)
line also depends on the settings of Switch 4 and Switch 6. Because there are no interconnections
between shelves, alarm monitoring is only available for Shelf A. If desired, all units can be
configured as Shelf A when using GR-303 to TR-08 translation.
Special TR-08 Settings
GR-303 provisioning for TR-08 Shelf B, C, D support requires the following settings for the DS1
drop lines. Other GR-303 settings remain the same. See GR-303 Provisioning Quick Guide on
page 10-9 .
Switch 4 Switch 6 Shelf Access Bank I/TR-08
Loopback Code Response
OFF OFF or
ON A Responds only to FDL (SLC-96 DDL) loopback codes
ON OFF B, C, D Responds to CSU loopback codes
ON ON B, C, D Does not respond to CSU loopback codes
CLI Commands TR-08 Item Descriptions
set ds1 framing slc96
set ds1 fdl slc96
DS1 drop to TR-08 Shelf A
set ds1 framing slc96
set ds1 fdl none
DS1 drop to TR-08 Shelf B, C, and D
set ds0 type voice
set ds0 type data
DS0 type for TR-08 voice channels
DS0 type for enhanced data services
set ds0 <n:ch> crv <range>
set ds0 <n:ch> crv <range> slc96
Assign CRVs in sequential order.
Assign CRVs in odd-even (slc96) order.
See Figure 10-3 and Figure 10-4.
