Access Navigator - Release 1.8 August 2003 13-13
Provision Remote Adit 600 via IP DS0
Provision Groom DS1s to Adit Router
3. Set DS1 out of service with the following command:
set ds1 down
Example: set ds1 32 down
4. Set DS1 type to “groom”
set ds1 type groom
Example: set ds1 32 type groom
5. Set DS1 framing to ESF (default) for Carrier Access IP DS0 management.
set ds1 framing esf
Example: set ds1 32 framing esf
6. Set DS1 line code to B8ZS (default) for Carrier Access IP DS0 management
set ds1 linecode b8zs
Example: set ds1 32 linecode b8zs
7. Set drop DS1 clock source to normal (default) for Carrier Access IP DS0 management
set ds1 clock normal
Example: set ds1 32 clock normal
8. Set drop DS1 line buildout (lbo) to required DSX-1 equalization or CSU attenuation. Setting 1 is
typical for a coloated Adit Router.
set ds1 lbo
Example: set ds1 32 lbo 1
The setting is a number from 1 to 9, and is defined as follows:
Setting Definition
1 Set DSX-1 equalization for 0-133 ft.
2 Set DSX-1 equalization for 133-266 ft.
3 Set DSX-1 equalization for 266-399 ft.
4 Set DSX-1 equalization for 399-533 ft.
5 Set DSX-1 equalization for 533-666 ft.
6 Set CSU attenuation for LBO of 0dB.
7 Set CSU attenuation for LBO of -7.5dB.
8 Set CSU attenuation for LBO of -15dB.
9 Set CSU attenuation for LBO of -22.5dB.
