6-12 August 2003 Access Navigator - Release 1.8
Electrical Installation
Connect DSX-1 Cables to Access Navigator
6. Connect DSX-1 transmit (output) interface cable to Access Navigator (see Figure 6-5).
7. Remove locking screw, if any, from DS1 Transmit (OUT) connector.
8. Plug transmit DSX-1 cable into DS1 Transmit (OUT) connector and snap clamp over cable side of
connector.
9. Position spade lug of shield drain wire under connector locking screw (#4-40 × 3/8") and tighten
with screw driver.
10. Verify that spade lug is firmly secured.
