Access Navigator - Release 1.8 August 2003 18-55
CLI Language Reference
CLI Command List
Read Remote T1drop
Reads and displays the T1drop settings from the remote Access Bank II at the far end of the Access Naviga-
tor’s DS1. The Access Bank II must be operational to read its settings. The command displays a message simi-
lar to the following.
Security: Level 3 (monitor)
Syntax: read remote <n> t1drop
Example: read remote 9 t1drop
Message:
T1DROP (T1#2):
CSU: On
LBO: CSU (0dB) / DSX-1 (0-133 ft.)
Linecode: B8ZS
Framing: ESF
PRM: ATT
Description:
Field Description
n DS1 number, 1 to 32.
Item Description
T1 ( ) T1 port connected to customer equipment: T1 #1, T1 #2.
CSU CSU loop code detection: On, Off.
LBO CSU attenuation (dB), DSX-1 equalization (ft.).
Linecode AMI, B8ZS.
Framing D4 (SF), ESF.
PRM Performance report message type:
ANSI – ANSI T1.403 performance messages.
ATT – AT&T 54016 maintenance messages.
