Access Navigator - Release 1.8
August 2003
6-5
Electrical
Installation
Chassis Ground Connection
Chassis Ground Connection
Installation Summary
n
n
n
Run Ground Wire to Access Navigator
n
Connect Ground Wire to Ground Lug
n
Attach Ground Lug to Access Navigator
Precautions
CAUTION!
C
HASSIS
MUST
BE
GROUNDED
FOR
COMPLIANCE
WITH
NEBS 1089
EMI/EMC
AND
FCC R
EQUIREMENT
P
ART
15,
TO
PREVENT
RADIO
FREQUENCY
INTERFERENCE
WITH
OTHER
EQUIPMENT
.
WARNING!
S
HEET
METAL
CAN
BE
DAMAGED
BY
BENDING
GROUND
WIRE
WHEN
GROUND
LUG
IS
ATTACHED
TO
A
CCESS
N
AVIGATOR
. B
EFORE
ATTACHING
GROUND
LUG
SCREWS
,
CAREFULLY
BEND
THE
GROUND
WIRE
TO
POSITION
THE
GROUND
LUG
OVER
THE
REAR
PANEL
TERMINALS
.
Tools and Materials
NOTE:
A ground lug with compression terminal is provided for attaching #6 or #8 AWG
insulated stranded copper wire. Follow standard practice for building ground systems.
Obtain the following tools and materials:
•
Screwdrivers, slotted
•
Screwdrivers, Phillips
•
Insulated copper wire, #6 or #8 AWG as required
•
Wire stripper
