Access Navigator - Release 1.8 August 2003 2-9
Access Navigator / DCS Service Manager
Compliance
Compliance
USA
l
UL 1950, 3rd Edition
l FCC Part 15, Class A
l
FCC Part 68
l NEBS Level 3 for Type 2 and 4 equipment
GR-1089-CORE
GR-63-CORE
CANADA
l CSA C22.2 No. 950.95
l ICES-003, Class A
l CS-03
Power
l Input power: –42 to –60 VDC @ 1.5A
l Dual feed DC power input terminals
l
Power dissipation: 65 watts (225 Btu/hr.), fully equipped
l
Solid-state (fuse-less) over-voltage and over-current protection
Environmental
l Operating temperature: –5°C to +45°C (23°F to 113°F), up to +55°C short term (NEBS)
l Solid-state over-temperature protection
l Relative humidity: 0 to 95%, non-condensing
l No fans; Passive thermal management
Physical
l Dimensions: 17" x 13.5" x 2.63"
l Weight: 10 lbs. (4.54 kg)
l Mounts in 19 and 23 inch racks
l
Optional wall mount brackets
