Access Navigator - Release 1.8 August 2003 13-21
Provision Remote Adit 600 via IP DS0
Provision DS0 Crossconnects
Provision DS0 Crossconnects
NOTE: Static DCS voice and data crossconnects, as well as ISDN BRI D (signaling)
channels, must be provisioned in the Access Navigator. Crossconnects are not required
for GR-303 voice and ISDN BRI B (bearer) channels because they are dynamically
assigned by the switch.
1. Show current crossconnect settings with the following command:
show connect
Example: show connect 10
The show command will display the current settings for the specified DS1. For example, the mes-
sage for DS1 number 11 would look similar to the following:
Connections for DS1 #10 (CA DS1# 10):
From To Type Interface [--> Port]
---- ----- ----- --------------------
10:01 ..... GR303
10:02 ..... GR303
10:03 ..... GR303
10:04 ..... GR303
10:05 ..... GR303
10:06 ..... GR303
10:07 ..... GR303
10:08 ..... GR303
10:09 ..... GR303
10:10 ..... GR303
10:11 ..... GR303
10:12 ..... GR303
10:13 .....
10:14 .....
10:15 .....
10:16 .....
10:17 17:12 DATA AcmeInternet --> V.35
10:18 17:13 DATA AcmeInternet --> V.35
10:19 17:14 DATA AcmeInternet --> V.35
10:20 17:15 DATA AcmeInternet --> V.35
10:21 17:16 DATA AcmeInternet --> V.35
10:22 17:17 DATA AcmeInternet --> V.35
10:23 17:18 DATA AcmeInternet --> V.35
10:24 32:10 DATA
NOTE:
For IP DS0 management, it is recommended that the management channel be
assigned to DS0 #24 on the drop DS1 to the remote Adit 600.
2. If DS0 crossconnect settings are correct, skip remaining steps.
