Syntax:
set ds1
Example:
set ds1 12 fdl none
Example:
set ds1 12 fdl t1403
Set DS1 Framing
Purpose:
Sets the DS1 framing type to D4, ESF, or SLC-96.
Switch DS1s for GR-303 use ESF. Drop DS1s to the Access Bank I/TR-08 use SLC-
96 framing. Drop DS1s to a remote Access Bank II use ESF framing, B8ZS line coding,
and CA FDL management. For Adit 600 drop DS1s, see Application Configuration
Requirements on
NOTE:
The service application affects the permissible DS1 Type, Framing,
Line Code, and FDL selections. For example, ESF is required for remote
provisioning, which uses the ESF FDL channel for management
communications. ESF is the default setting for the Access Bank II.
Security:
Level 2 (operator)
Syntax:
set ds1 <n> framing <d4|esf|slc96>
Example:
set ds1 9 framing esf
Field
Description
n
DS1 number, 1 to 32, or a range of numbers such as 2-8.
none
Disable FDL. (This is the required setting for remote
management of Adit 600 terminals. See Set DS1 Remote Device
Mgmt on
slc96
Enable communications with Shelf A of SLC-96/TR-08 group.
(Supports Access Bank I/TR-08 and line loopback commands.)
t1403
Enable detection and response to ANSI T1.403 bit-patterned
codes over the FDL.
Field
Description
n
DS1 number, 1 to 32, or a range of numbers such as 2-8.
d4
Set DS1 to D4 framing.
esf
Set DS1 to ESF framing.
slc96
Set DS1 to SLC-96/TR-08 framing.
