Access Navigator - Release 1.8 August 2003 9-15
Provision DCS Service
Provision “Drop” DS1 Circuits to Subscribers
3. Set DS1 type to “drop” with the following command:
set ds1 type drop
Example: set ds1 20 type drop
4. Set drop DS1 frame type to D4 or ESF with the following command:
set ds1 framing
Example: set ds1 20 framing esf
5. Set drop DS1 line code to AMI or B8ZS with the following command:
set ds1 linecode
Example: set ds1 20 linecode b8zs
6. Set drop DS1 circuit ID with the following command:
set ds1 id <"id">
Example: set ds1 20 id "Acme Corp DS1#20"
The ID may contain up to 30 characters and must be enclosed in quote marks.
7. Set drop DS1 clock source to normal or loop with the following command:
set ds1 clock
Example: set ds1 20 clock normal
8. Set drop DS1 line buildout (lbo) to required DSX-1 equalization or CSU attenuation with the
following command:
set ds1 lbo
Example: set ds1 20 lbo 8
The setting is a number from 1 to 9, and is defined as follows:
Setting Definition
1 Set DSX-1 equalization for 0-133 ft.
2 Set DSX-1 equalization for 133-266 ft.
3 Set DSX-1 equalization for 266-399 ft.
4 Set DSX-1 equalization for 399-533 ft.
5 Set DSX-1 equalization for 533-666 ft.
6 Set CSU attenuation for LBO of 0dB.
7 Set CSU attenuation for LBO of -7.5dB.
8 Set CSU attenuation for LBO of -15dB.
9 Set CSU attenuation for LBO of -22.5dB.
NOTE: When loop request code detection is turned on, the Access Navigator will
respond to T1.403 ESF bit patterned loop requests.
9. Set drop DS1 loop request code detection to on or off with the following command:
set ds1 loopdetect
Example: set ds1 20 loopdetect on
