Access Navigator - Release 1.8
August 2003
5-7
Physical
Installation
Horizontal 23-Inch Rack Mount
Horizontal 23-Inch Rack Mount
Installation Summary
n
n
n
Attach Mounting Brackets to Access Navigator
n
Attach Access Navigator to Equipment Rack
Precautions
CAUTION!
A
CCESS
N
AVIGATOR
REQUIRES
AT
LEAST
4.37
INCHES
(2.5
RACK
UNITS
)
OF
FREE
AIR
SPACE
ABOVE
AND
BELOW
CHASSIS
FOR
AIR
CIRCULATION
.
I
NSUFFICIENT
SPACING
MAY
CAUSE
SERVICE
INTERRUPTIONS
,
RESULTING
FROM
EQUIPMENT
OVERHEATING
AND
SHUTTING
DOWN
.
Tools and Materials
Obtain the following tools and materials:
•
Phillips screw drivers, #2 and #3
•
Universal rack mounting bracket kit, PN 710-0153, included with Access Navigator
•
Rack mounting screws (4 ea.), as appropriate for equipment rack
NOTE:
Rack mounting brackets come with hardware for installation in both 19-inch and
23-inch equipment racks. Some hardware is not required for 19-inch rack installation.
