18-162 August 2003 Access Navigator - Release 1.8
CLI Language Reference
CLI Command List
Status DS1 Performance
Purpose: Displays current performance data for the specified DS1. The Access Navigator
accumulates DS1 performance data for the parameters described in RFC 1406 –
Definitions of Managed Objects for the DS1 and E1 Interface Types. All performance
parameters are accumulated in fifteen minute intervals. The “current” 15 minute
interval shows data collected when the command is received, and always represents an
elapsed time of less than 15 minutes. At the end of each 15 minute interval, the Access
Navigator displays the total as the “previous” 15 minute interval and computes new
totals for 1 hour and 1 day by summing previous intervals.
Each DS1 has its own interval timer (not the system clock) that controls all
measurement intervals. This timer counts from zero up to 24 hours, then rolls over and
starts at zero again. This timer is reset by a power-on reset or reset all command.
To see data for the most recent 96 intervals, see Status DS1 Performance History on
page 18-165 .
NOTE: The clear performance command can be used to reset the
performance data for a specific DS1. When this is done, the timer for that DS1
will start at zero hours, minutes, and seconds. (See “Clear DS1 Performance”
on page 18-27.)
Status In use as DROP – Subscriber “drop” DS1.
In use as GROOM – DCS “groom” DS1.
In Service – GR-303 “switch” DS1.
User set Out of Service – User set DS1 down.
Card Not Installed – Empty card slot
(The CLI also displays alarm messages such as RAI.)
FDL None – No detection or response (default for switch DS1s).
CAC – Required to provision remote Access Bank II.
SLC96 – Required for Shelf A of SLC-96/TR-08 group.
T1403 – Detects and responds to ANSI T1.403 codes.
Remote Device
Management n/a – not applicable
CA FDL – Used to provision remote Access Bank II or
establish pass-through management session to Adit 600.
CA IP – Used for IP DS0 management of
remote Adit 600.
CA DS1 <n> – Used for IP DS0 management of remote
Adit 600.
In Service – Management link is in service (up)
Out of Service – Management link is out of service (down).
(See Set DS1 Remote Device Mgmt on
page 18-113 .)
Clock Source Indicates Primary or Secondary if DS1 line receiver is used for
master clock source
Item Description
