6-8 August 2003 Access Navigator - Release 1.8
Electrical Installation
DSX-1 Cable Connections
DSX-1 Cable Connections
Installation Summary
n Precautions ... 6-8
n Tools and Materials ... 6-9
n Prepare DSX-1 Cables ... 6-9
n Connect DSX-1 Cables to Access Navigator ... 6-11
n Attach Ferrite Beads ... 6-13
n Connect DSX-1 Cables to Interface or Patch Panel ... 6-14
Precautions
CAUTION! S HIELDED DSX-1 CABLES WITH FERRITE BEAD RF SUPPRESSORS ARE
REQUIRED FOR COMPLIANCE WITH NEBS 1089 EMI/EMC AND FCC R EQUIREMENT
P ART 15, TO PREVENT RADIO FREQUENCY INTERFERENCE WITH OTHER EQUIPMENT .
CAUTION! DSX-1 CABLES HAVE SOLID CONDUCTOR WIRES . I F ATTACHING RJ
TYPE CONNECTORS TO FLYING WIRE CABLES , BE SURE TO USE RJ CONNECTORS
DESIGNED FOR SOLID WIRE . U SING RJ CONNECTORS DESIGNED FOR STRANDED WIRE
WILL CAUSE POOR SIGNAL CONNECTIONS AND SERVICE DISRUPTIONS .
WARNING! NEBS R EQUIREMENT . D O NOT CONNECT THIS EQUIPMENT DIRECTLY
TO METALLIC TIP - AND - RING OUTSIDE PLANT CONDUCTORS . T HIS EQUIPMENT CAN ONLY
BE USED FOR INTRA - BUILDING ( INSIDE PLANT ) INSTALLATION IN A CENTRAL OFFICE OR
CUSTOMER PREMISES .
