756
Chapter 36 Input Capture
7.Q&A
Interrupt request flags (ICS01.ICP0), (ICS01.ICP1), (ICS23.ICP0), (ICS23.ICP1), (ICS45.ICP0), (ICS45.ICP1),
(ICS67.ICP0), (ICS67.ICP1) are not automatically cleared, so please set the input capture interrupt request
flag (ICP1, ICP0) to “0” to clear them before returning from interrupt processing.
7.4 What are the types of interrupts?
There is only one kind of interrupt, and it is generated by input signal edge detection.
7.5 How do I enable interrupts?
Interrupt request permission, interrupt request flag
Interrupts are enabled via interrupt request permission bit (ICS01.ICE0), (ICS01.ICE1), (ICS23.ICE0),
(ICS23.ICE1), (ICS45.ICE0), (ICS45.ICE1), (ICS67.ICE0), (ICS67.ICE1).
Clearing of interrupt requests is done using interrupt request bit (ICS01.ICP0), (ICS01.ICP1), (ICS23.ICP0),
(ICS23.ICP1), (ICS45.ICP0), (ICS45.ICP1), (ICS67.ICP0), (ICS67.ICP1).
Input Capture 6
#98
Address: 0FFE74h
Interrupt level register (ICR41)
Address: 0469h
Input Capture 7
#99
Address: 0FFE70h
Interrupt request permission bit (ICE0), (CE1)
Disable interrupts Set to “0”
Enable interrupts Set to “1”
Interrupt request bit (ICP0), (ICP1)
Interrupt request clear Write “0”
