AT8404
Switching Commands
Page 2 - 49
AT8404 CLI Reference Manual
If you use the optional parameter summary {
or all ports are displayed.
If you use the optional parameter 'detail
displayed.
VLAN Assignment
Mode
Indicates whether assignment of an authorized port to a RADIUS assigned VLAN is allowed
(enabled) or not (disabled).
Term
Definition
Interface
The interface whose configuration is displayed.
Control Mode
The configured control mode for this port. Possible values are force-unauthorized | force-
authorized | auto | authorized | unauthorized.
Operating Control
Mode
The control mode under which this port is operating. Possible values are authorized |
unauthorized.
Reauthentication
Enabled
Indicates whether re-authentication is enabled on this port.
Port Status
Indicates whether the port is authorized or unauthorized. Possible values are authorized |
unauthorized.
Term
Definition
Port
The interface whose configuration is displayed.
Protocol Version
The protocol version associated with this port. The only possible value is 1, corresponding to
the first version of the dot1x specification.
PAE Capabilities
The port access entity (PAE) functionality of this port. Possible values are Authenticator or
Supplicant.
Authenticator PAE
State
Current state of the authenticator PAE state machine. Possible values are Initialize,
Disconnected, Connecting, Authenticating, Authenticated, Aborting, Held, ForceAuthorized,
and ForceUnauthorized.
Backend
Authentication
State
Current state of the backend authentication state machine. Possible values are Request,
Response, Success, Fail, Timeout, Idle, and Initialize.
Quiet Period
The timer used by the authenticator state machine on this port to define periods of time in
which it will not attempt to acquire a supplicant. The value is expressed in seconds and will
be in the range 0 and 65535.
Transmit Period
The timer used by the authenticator state machine on the specified port to determine when to
send an EAPOL EAP Request/Identity frame to the supplicant. The value is expressed in
seconds and will be in the range of 1 and 65535.
Guest-VLAN ID
The guest VLAN identifier configured on the interface.
Guest-Vlan
Operational Mode
Indicates whether guest-vlan operational mode is enabled or disabled.
Supplicant
Timeout
The timer used by the authenticator state machine on this port to timeout the supplicant. The
value is expressed in seconds and will be in the range of 1 and 65535.
Server Timeout
The timer used by the authenticator on this port to timeout the authentication server. The
value is expressed in seconds and will be in the range of 1 and 65535.
Maximum
Requests
The maximum number of times the authenticator state machine on this port will retransmit an
EAPOL EAP Request/Identity before timing out the supplicant. The value will be in the range
of 1 and 10.
Vlan-assigned
The VLAN assigned to the port by the radius server.
Term
Definition
