Quality of Service (QoS) Commands AT8404
AT8404 CLI Reference Manual Page 3 - 24
The following information is repeated for each class associated with this policy (only those policy attributes actually
configured are displayed):
If the Policy Name is not specified this command displays a list of all defined DiffServ policies. The following fields
are displayed:
Term Definition
Assign Queue Directs traffic stream to the specified QoS queue. This allows a traffic classifier to specify
which one of the supported hardware queues are used for handling packets belonging to the
class.
Class Name The name of this class.
Committed Burst
Size (KB)
The committed burst size, used in simple policing.
Committed Rate
(Kbps)
The committed rate, used in simple policing,
Conform Action The current setting for the action taken on a packet considered to conform to the policing
parameters. This is not displayed if policing is not in use for the class under this policy.
Conform COS The CoS mark value if the conform action is set-cos-transmit.
Conform DSCP
Value
The DSCP mark value if the conform action is set-dscp-transmit.
Conform IP
Precedence Value
The IP Precedence mark value if the conform action is set-prec-transmit.
Drop Drop a packet upon arrival. This is useful for emulating access control list operation using
DiffServ, especially when DiffServ and ACL cannot co-exist on the same interface.
Mark CoS The class of service value that is set in the 802.1p header of inbound packets. This is not
displayed if the mark cos was not specified.
Mark IP DSCP The mark/re-mark value used as the DSCP for traffic matching this class. This is not displayed
if mark ip description is not specified.
Mark IP
Precedence
The mark/re-mark value used as the IP Precedence for traffic matching this class. This is not
displayed if mark ip precedence is not specified.
Mirror Copies a classified traffic stream to a specified egress port (physical port or LAG). This can
occur in addition to any marking or policing action. It may also be specified along with a QoS
queue assignment. This field does not display on Broadcom 5630x platforms.
Non-Conform
Action
The current setting for the action taken on a packet considered to not conform to the policing
parameters. This is not displayed if policing not in use for the class under this policy.
Non-Conform COS The CoS mark value if the non-conform action is set-cos-transmit.
Non-Conform
DSCP Value
The DSCP mark value if the non-conform action is set-dscp-transmit.
Non-Conform IP
Precedence Value
The IP Precedence mark value if the non-conform action is set-prec-transmit.
Policing Style The style of policing, if any, used (simple).
Redirect Forces a classified traffic stream to a specified egress port (physical port or LAG). This can
occur in addition to any marking or policing action. It may also be specified along with a QoS
queue assignment. This field does not display on Broadcom 5630x platforms.
Term
Definition
Policy Name The name of this policy. (The order in which the policies are displayed is not necessarily the
same order in which they were created.)
Policy Type The policy type (Only inbound is supported).
Class Members List of all class names associated with this policy.
