AT8404 Quality of Service (QoS) Commands
Page 3 - 27 AT8404 CLI Reference Manual
3.7.1 mac access-list extended
This command creates a MAC Access Control List (ACL) identified by , consisting of classification fields
defined for the Layer 2 header of an Ethernet frame. The parameter is a case-sensitive alphanumeric string
from 1 to 31 characters uniquely identifying the MAC access list.
If a MAC ACL by this name already exists, this command enters Mac-Access-List config mode to allow updating the
existing MAC ACL.
3.7.1.1 no mac access-list extended
This command deletes a MAC ACL identified by from the system.
3.7.2 mac access-list extended rename
This command changes the name of a MAC Access Control List (ACL). The parameter is the name of an
existing MAC ACL. The parameter is a case-sensitive alphanumeric string from 1 to 31 characters
uniquely identifying the MAC access list.
This command fails if a MAC ACL by the name already exists.
3.7.3 {deny | permit} (MAC ACL)
This command creates a new rule for the current MAC access list. Each rule is appended to the list of configured
rules for the list.
Note: The CLI mode changes to Mac-Access-List Config mode when you successfully execute this
command.
Format mac access-list extended
Mode Global Config
Format no mac access-list extended
Mode Global Config
Format mac access-list extended rename
Mode Global Config
Note: The 'no' form of this command is not supported, since the rules within a MAC ACL cannot be
deleted individually. Rather, the entire MAC ACL must be deleted and re-specified.
Note: An implicit 'deny all' MAC rule always terminates the access list.
Note: For BCM5630x and BCM5650x based systems, assign-queue, redirect, and mirror attributes are
configurable for a deny rule, but they have no operational effect.
