AT8404 Switching Commands
Page 2 - 41 AT8404 CLI Reference Manual
2.10.4 show mac-address-table gmrp
This command displays the GMRP entries in the Multicast Forwarding Database (MFDB) table.
2.11 Port-Based Network Access Control Commands
This section describes the commands you use to configure port-based network access control (802.1x). Port-based
network access control allows you to permit access to network services only to and devices that are authorized and
authenticated.
2.11.1 authentication login
This command creates an authentication login list. The is any character string and is not case
sensitive. Up to 10 authentication login lists can be configured on the switch. When a list is created, the
authentication method “local” is set as the first method.
When the optional parameters “Option1”, “Option2” and/or “Option3” are used, an ordered list of methods are set in
the authentication login list. If the authentication login list does not exist, a new authentication login list is first created
Join Timer The interval between the transmission of GARP PDUs registering (or re-registering)
membership for an attribute. Current attributes are a VLAN or multicast group. There is an
instance of this timer on a per-port, per-GARP participant basis. Permissible values are 10 to
100 centiseconds (0.1 to 1.0 seconds). The factory default is 20 centiseconds (0.2 seconds).
The finest granularity of specification is 1 centisecond (0.01 seconds).
Leave Timer The period of time to wait after receiving an unregister request for an attribute before deleting
the attribute. Current attributes are a VLAN or multicast group. This may be considered a
buffer time for another station to assert registration for the same attribute in order to maintain
uninterrupted service. There is an instance of this timer on a per-Port, per-GARP participant
basis. Permissible values are 20 to 600 centiseconds (0.2 to 6.0 seconds). The factory default
is 60 centiseconds (0.6 seconds).
LeaveAll Timer This Leave All Time controls how frequently LeaveAll PDUs are generated. A LeaveAll PDU
indicates that all registrations will shortly be deregistered. Participants will need to rejoin in
order to maintain registration. There is an instance of this timer on a per-Port, per-GARP
participant basis. The Leave All Period Timer is set to a random value in the range of
LeaveAllTime to 1.5*LeaveAllTime. Permissible values are 200 to 6000 centiseconds (2 to 60
seconds). The factory default is 1000 centiseconds (10 seconds).
Port GMRP Mode The GMRP administrative mode for the port. It may be enabled or disabled. If this parameter
is disabled, Join Time, Leave Time and Leave All Time have no effect.
Format show mac-address-table gmrp
Mode Privileged EXEC
Term Definition
Mac Address A unicast MAC address for which the switch has forwarding and or filtering information. The
format is 6 or 8 two-digit hexadecimal numbers that are separated by colons, for example
01:23:45:67:89:AB. In an IVL system the MAC address is displayed as 8 bytes.
Type The type of the entry. Static entries are those that are configured by the end user. Dynamic
entries are added to the table as a result of a learning process or protocol.
Description The text description of this multicast table entry.
Interfaces The list of interfaces that are designated for forwarding (Fwd:) and filtering (Flt:).
Term Definition
