Quality of Service (QoS) Commands AT8404
AT8404 CLI Reference Manual Page 3 - 22
3.6 DiffServ Show Commands
Use the DiffServ show commands to display configuration and status information for classes, policies, and services.
You can display DiffServ information in summary or detailed formats. The status information is only shown when the
DiffServ administrative mode is enabled.
3.6.1 show class-map
This command displays all configuration information for the specified class. The is the name of
an existing DiffServ class.
If the class-name is specified the following fields are displayed:
If you do not specify the Class Name, this command displays a list of all defined DiffServ classes. The following fields
are displayed:
Format no service-policy in
Modes • Global Config
• Interface Config
Format show class-map
Modes • Privileged EXEC
• User EXEC
Term Definition
Class Name The name of this class.
Class Type A class type of ‘all’ means every match criterion defined for the class is evaluated
simultaneously and must all be true to indicate a class match.
L3 Proto The Layer 3 protocol for this class. Possible values are IPv4 and IPv6.
Match Criteria The Match Criteria fields are only displayed if they have been configured. Not all platforms
support all match criteria values. They are displayed in the order entered by the user. The
fields are evaluated in accordance with the class type. The possible Match Criteria fields are:
Destination IP Address, Destination Layer 4 Port, Destination MAC Address, Ethertype,
Source MAC Address, VLAN, Class of Service, Every, IP DSCP, IP Precedence, IP TOS,
Protocol Keyword, Reference Class, Source IP Address, and Source Layer 4 Port.
Values The values of the Match Criteria.
Term Definition
Class Name The name of this class. (Note that the order in which classes are displayed is not necessarily
the same order in which they were created.)
Class Type A class type of ‘all’ means every match criterion defined for the class is evaluated
simultaneously and must all be true to indicate a class match.
Ref Class Name The name of an existing DiffServ class whose match conditions are being referenced by the
specified class definition.
