AT8404 Quality of Service (QoS) Commands
Page 3 - 13 AT8404 CLI Reference Manual
need not be contiguous, and is formatted as six, two-digit hexadecimal numbers separated by colons (e.g.,
ff:07:23:ff:fe:dc).
3.3.9 match dstip
This command adds to the specified class definition a match condition based on the destination IP address of a
packet. The parameter specifies an IP address. The parameter specifies an IP address bit
mask and must consist of a contiguous set of leading 1 bits.
3.3.10 match dstip6
This command adds to the specified class definition a match condition based on the destination IPv6 address of a
packet.
3.3.11 match dstl4port
This command adds to the specified class definition a match condition based on the destination layer 4 port of a
packet using a single keyword or numeric notation. To specify the match condition as a single keyword, the value
for is one of the supported port name keywords. The currently supported values are:
domain, echo, ftp, ftpdata, http, smtp, snmp, telnet, tftp, www. Each of these translates into its equivalent port
number. To specify the match condition using a numeric notation, one layer 4 port number is required. The port
number is an integer from 0 to 65535.
3.3.12 match ip dscp
This command adds to the specified class definition a match condition based on the value of the IP DiffServ Code
Point (DSCP) field in a packet, which is defined as the high-order six bits of the Service Type octet in the IP header
(the low-order two bits are not checked).
Note: This command is not available on the Broadcom 5630x platform.
Default none
Format match destination-address mac
Mode Class-Map Config
Default none
Format match dstip
Mode Class-Map Config
Default none
Format match dstip6
Mode Ipv6-Class-Map Config
Default none
Format match dstl4port { | <0-65535>}
Mode Ipv6-Class-Map Config
Class-Map Config
