AT8404 Switching Commands
Page 2 - 77 AT8404 CLI Reference Manual
2.15 Static MAC Filtering
The commands in this section describe how to configure static MAC filtering. Static MAC filtering allows you to
configure destination ports for a static multicast MAC filter irrespective of the platform.
2.15.1 macfilter
This command adds a static MAC filter entry for the MAC address <macaddr> on the VLAN <vlanid>. The value
of the <macaddr> parameter is a 6-byte hexadecimal number in the format of b1:b2:b3:b4:b5:b6. The restricted
MAC Addresses are: 00:00:00:00:00:00, 01:80:C2:00:00:00 to 01:80:C2:00:00:0F, 01:80:C2:00:00:20 to
01:80:C2:00:00:21, and FF:FF:FF:FF:FF:FF. The <vlanid> parameter must identify a valid VLAN.
The number of static mac filters supported on the system is different for MAC filters where source ports are
configured and MAC filters where destination ports are configured.
• For unicast MAC address filters and multicast MAC address filters with source port lists, the maximum number
of static MAC filters supported is 20.
• For multicast MAC address filters with destination ports configured, the maximum number of static filters
supported is 256.
i.e. For current Broadcom platforms, you can configure the following combinations:
• Unicast MAC and source port (max = 20)
• Multicast MAC and source port (max=20)
• Multicast MAC and destination port (only) (max=256)
• Multicast MAC and source ports and destination ports (max=20)
2.15.1.1 no macfilter
This command removes all filtering restrictions and the static MAC filter entry for the MAC address on
the VLAN . The parameter must be specified as a 6-byte hexadecimal number in the format
of b1:b2:b3:b4:b5:b6.
The parameter must identify a valid VLAN.
Monitor Session
Mode
Indicates whether the Port Mirroring feature is enabled or disabled for the session identified
with . The possible values are Enabled and Disabled.
Probe Port Probe port (destination port) for the session identified with . If probe port is
not set then this field is blank.
Source Port The port, which is configured as mirrored port (source port) for the session identified with
. If no source port is configured for the session then this field is blank.
Type Direction in which source port configured for port mirroring.Types are tx for transmitted
packets and rx for receiving packets.
Format macfilter
Mode Global Config
Format no macfilter
Mode Global Config
Term Definition
