Rockwell Automation Publication 193-UM015B-EN-P - June 2014

97

Protective Trip and Warning Functions Chapter 5

Stall Enabled Time

Stall Enabled Time (Parameter 249) allows the user to adjust the time the E300
Electronic Overload Relay monitors for a stall condition during the motor
starting sequence and is adjustable from 0…250 s.

Table 79 - Stall Enabled Time (Parameter 249)

Stall Trip Level

Stall Trip Level (Parameter 250) allows the installer to define the locked rotor
current and is adjustable from 100…600% of the FLA Setting (Parameter 171).

IMPORTANT

The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:

Output PT00 Protection Fault Action (Parameter 304)

Output PT00 Protection Fault Value (Parameter 305)

Output PT01 Protection Fault Action (Parameter 310)

Output PT01 Protection Fault Value (Parameter 311)

Output PT02 Protection Fault Action (Parameter 316)

Output PT02 Protection Fault Value (Parameter 317)

Output Digital Module 1 Protection Fault Action (Parameter 322)

Output Digital Module 1 Protection Fault Value (Parameter 323)

Output Digital Module 2 Protection Fault Action (Parameter 328)

Output Digital Module 2 Protection Fault Value (Parameter 329)

Output Digital Module 3 Protection Fault Action (Parameter 334)

Output Digital Module 3 Protection Fault Value (Parameter 335)

Output Digital Module 4 Protection Fault Action (Parameter 340)

Output Digital Module 4 Protection Fault Value (Parameter 342)

Stall Enabled Time (Parameter 249)

Default Value

10

Minimum Value

0

Maximum Value

250

Parameter Type

USINT

Size (Bytes)

1

Scaling Factor

1

Units

Sec
