Rockwell Automation Publication 193-UM015B-EN-P - November 2013 363
Parameter List Appendix B
Analog2 Setup
(continued)
485 InAMod2C1WarnLvl Level (in selected Units) where
Analog Input generates a
warning UINT 2 1 0 65535 0
486 InAnMod2Ch02Type Assignment for Analog Module 2
Input Channel 02 function USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
6= 100Pt385
7= 200Pt385
8= 500Pt385
9= 1000Pt385
10=100Pt3916
11= 200Pt3916
12= 500Pt3916
13= 1000Pt3916
14= 10Cu426
15= 120Ni618
16= 120Ni672
17= 604NiFe518
18= 150ohm
19= 1000ohm
20 = 3000ohm
21= 6000ohm 0
487 InAMod2Ch2Format Assignment for Analog Module 2
Input Channel 02 Data Format USINT 1 1 0= EngUnits
1= EngUnitsTimes10
2= RawProportional
3= ScaledForPID 0
488 InAMod2C2TmpUnit Assignment for Analog Module 2
Input Channel 02 Temperature
Units USINT 1 1 0=DegreesC
1=DegreesF 0
489 InAMod2C2FiltFrq Assignment Analog Module 2
Input Channel 02 Filter Freq USINT 1 1 0=17Hz
1=4Hz
2=62Hz
3=470Hz 0
490 InAMod2C2OpCktSt Indicates Analog Module 2 Input
Channel 02 Open Circuit State USINT 1 1 0=Upscale
1=Downscale
2=Zero 0
491 InAnMod2Ch2RTDEn Enable Analog Module 2 Input
Channel 02 to function with RTD BOOL 1 1 0=3-wire
1=2-wire 0
492 InAMod2C2TripDly Analog Module 2 Input Channel
02 Trip Delay USINT 1 10 0 250 10 Sec
493 InAMod2C2TripLvl Level (in selected Units) where
Analog Input generates a trip UINT 2 1 0 65535 0
494 InAMod2C2WarnLvl Level (in selected Units) where
Analog Input generates a
warning UINT 2 1 0 65535 0
495 OutAnMod2Type Assignment for Analog Module 2
Output function. USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4=ITo5 Volts
5=OTo5 Volts 0
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
