Rockwell Automation Publication 193-UM015B-EN-P - November 2013

361

Parameter List Appendix B

Analog1 Setup

(continued)

465

OutAnMod1Select

Assignment of parameter data
value to drive Analog Module 1
Output

USINT

1

1

0= AveragePctFLA
1= ScaledAvgPctFLA
2= PercentTCU
3= GFCurrent
4= CurrentUnbalance
5= AvgLLVoltage
6=VoltLLUnbalance
7= TotalkW
8= TotalkVA
9= TotalkVAR
10= TotalPF
11= UserDLXData

0

466

OutAnMod1FltActn

Analog Module 1 Output action
on comms fault

USINT

1

1

0= Zero
1= Maximum
2= Minimum
3= Hold Last State

0

467

OutAnMod1IdlActn

Analog Module 1 Output action
on comms idle

USINT

1

1

0= Zero
1= Maximum
2= Minimum
3= Hold Last State

0

Analog2 Setup

468

InAnMod2Ch00Type

Assignment for Analog Module 2
Input Channel 00 function

USINT

1

1

0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
6= 100Pt385
7= 200Pt385
8= 500Pt385
9= 1000Pt385
10=100Pt3916
11= 200Pt3916
12= 500Pt3916
13= 1000Pt3916
14= 10Cu426
15= 120Ni618
16= 120Ni672
17= 604NiFe518
18= 150ohm
19= 1000ohm
20 = 3000ohm
21= 6000ohm

0

469

InAMod2Ch0Format

Assignment for Analog Module 2
Input Channel 00 Data Format

USINT

1

1

0= EngUnits
1= EngUnitsTimes10
2= RawProportional
3= ScaledForPID

0

470

InAMod2C0TmpUnit

Assignment for Analog Module 2
Input Channel 00 Temperature
Units

USINT

1

1

0=DegreesC
1=DegreesF

0

471

InAMod2C0FiltFrq

Assignment for Analog Module 2
Input Channel 00 Filter Freq

USINT

1

1

0=17Hz
1=4Hz
2=62Hz
3=470Hz

0

Group

Param

No.

Parameter Name

Description

Type

Data Size

(bytes)

Scale

Factor

Min

Max

Default Units
