254 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
Energy Monitor The E300 Electronic Overload Relay’s energy monitor diagnostics provides
information on the electrical energy being consumed by the load. The energy
diagnostics include kWh, kVARh, kVAh, kW Demand, kVAR Demand, and kVA
Demand.
kWh 10
9
kWh 10
9
(Parameter 80) reports a component of total real energy (kWh).
Multiply this value by 10
9
and add to the other kWh parameters.
Represents XXX,000,000,000.000 kWh
Table 285 - kWh x 10E9 (Parameter 80)
kWh 10
6
kWh 10
6
(Parameter 81) reports a component of total real energy (kWh).
Multiply this value by 10
6
and add to the other kWh parameters.
Represents 000,XXX,000,000.000 kWh
Table 286 - kWh x 10E6 (Parameter 81)
Units %
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
