276 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
Trip Snapshot L2-L3 Voltage
Trip Snapshot L2-L3 Voltage (Parameter 157) reports the voltage in volts in
reference to the T2 and T3 power terminals of the E300 Electronic Overload
Relay Sensing Module at the time of the most recent trip event.
Table 327 - Trip Snapshot L2-L3 Voltage (Parameter 157)
Trip Snapshot L3-L1 Voltage
Trip Snapshot L3-L1 Voltage (Parameter 158) reports the voltage in volts in
reference to the T3 and T1 power terminals of the E300 Electronic Overload
Relay Sensing Module at the time of the most recent trip event.
Table 328 - Trip Snapshot L3-L1 Voltage (Parameter 158)
Trip Snapshot Total Real Power
Trip Snapshot Total Real Power (Parameter 159) reports the total real power of
the monitored power conductors in kW at the time of the most recent trip event.
Table 329 - Trip Snapshot Total Real Power (Parameter 159)
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.000
Minimum Value -2000000.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kW
