Rockwell Automation Publication 193-UM015B-EN-P - June 2014
153
Protective Trip and Warning Functions Chapter 5
•
Under Reactive Power (kVA) Trip/Warning
•
Over Real Power (kVA) Trip/Warning
•
Under Power Factor Trip/Warning
•
Over Power Factor Trip/Warning
Power Trip Enable (Parameter 185) and Power Warning Enable (Parameter 191)
are used to enable the respective power based protective trip and warning
functions.
Table 144 - Power Trip Enable (Parameter 185)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
X
Under kW Trip
X
Over kW Trip
X
Under kVAR Consumed Trip
X
Over kVAR Consumed Trip
X
Under kVAR Generated Trip
X
Over kVAR Generated Trip
X
Under kVA Trip
X
Over kVA Trip
X
Under PF Lagging Trip
X
Over PF Lagging Trip
X
Under PF Leading Trip
X
Over PF Leading Trip
Reserved
Reserved
Reserved
Reserved
