244 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
L1-N Voltage
L1-N Voltage (Parameter 57) reports the voltage in volts in reference to the T1
power terminal of the E300 Electronic Overload Relay Sensing Module.
Table 261 - L1-N Voltage (Parameter 57)
L2-N Voltage
L2-N Voltage (Parameter 58) reports the voltage in volts in reference to the T2
power terminal of the E300 Electronic Overload Relay Sensing Module.
Table 262 - L2-N Voltage (Parameter 58)
L3-N Voltage
L3-N Voltage (Parameter 59) reports the voltage in volts in reference to the T3
power terminal of the E300 Electronic Overload Relay Sensing Module.
Table 263 - L3-N Voltage (Parameter 59)
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
