246 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
Frequency
Frequency (Parameter 62) reports the voltage frequency in Hertz of the
monitored power system from the E300 Electronic Overload Relay Sensing
Module.
Table 266 - Frequency (Parameter 62)
Phase Rotation
Phase Rotation (Parameter 63) reports the voltage phase rotation as ABC or
ACB of the monitored power system from the E300 Electronic Overload Relay
Sensing Module.
Table 267 - Phase Rotation Trip Type (Parameter 63)
Power Monitor The E300 Electronic Overload Relay’s power monitor diagnostics provides
information on the power being supplied to the load. The power diagnostics
include real power (kW), reactive power (kVAR), apparent power (kVA), and
power factor.
Size (Bytes) 2
Scaling Factor 1
Units %
Default Value 0.0
Minimum Value 0.0
Maximum Value 74.0
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Hz
Default Value 0 = No Rotation
Range
0 = No Rotation
1 = ABC
2 = ACB
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units
