Rockwell Automation Publication 193-UM015B-EN-P - June 2014 259
Metering and Diagnostics Chapter 7
kVARh Generated 10
3
kVARh Generated 10
3
(Parameter 92) reports a component of total reactive
energy generated (kVARh). Multiply this value by 10
3
and add to the other
kVARh Generated parameters.
Represents 000,000,XXX,000.000 kVARh
Table 297 - kVARh Generated x 10E3 (Parameter 92)
kVARh Generated 10
0
kVARh Generated 10
0
(Parameter 93) reports a component of total reactive
energy generated (kVARh). Multiply this value by 10
0
and add to the other
kVARh Generated parameters.
Represents 000,000,000,XXX.000 kVARh
Table 298 - kVARh Generated x 10E0 (Parameter 93)
kVARh Generated 10
-3
kVARh Generated 10
-3
(Parameter 94) reports a component of total reactive
energy generated (kVARh). Multiply this value by 10
-3
and add to the other
kVARh Generated parameters.
Represents 000,000,000,000. XXX kVARh
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
