Appendix C EtherNet/IP Information
Connection Object — CLASS CODE 0x0005
No class attributes are supported for the Connection Object
Multiple instances of the Connection Object are supported, instances 1, 2 and 4
from the group 2 predefined master/slave connection set, and instances 5-7 are
available explicit UCMM connections.
Instance 1 is the Predefined Group 2 Connection Set Explicit Message
Connection. The following instance 1 attributes are supported:
Table 378 - Connection Object — CLASS CODE 0x0005 Instance 1 Attributes
Attribute ID Access Rule Name Data Type Value
1 Get State USINT
0=nonexistant
1=configuring
3=established
4=timed out
2 Get Instance Type USINT
0=Explicit
Message
3 Get Transport Class Trigger USINT 0x83 - Server, Transport Class 3
4 Get Produced Connection ID UINT
10xxxxxx011
xxxxxx = node address
5 Get Consumed Connection ID UINT
10xxxxxx100
xxxxxx = node address
6 Get Initial Comm Characteristics USINT 0x22
7 Get Produced Connection Size UINT 0x61
8 Get Consumed Connection Size UINT 0x61
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get Watchdog Action USINT
01 = auto delete
03 = deferred delete
13 Get Produced Connection Path Length UINT 0
14 Get Produced Connection Path Empty
15 Get Consumed Connection Path Length UINT 0
16 Get Consumed Connection Path Empty
