Rockwell Automation Publication 193-UM015B-EN-P - June 2014 323
Appendix
A
Specifications
Electrical Specifications
➊ Exception: Any E300 Overload Relay that uses an external ground fault sensor is limited to 50/60 Hz detection.
Table 343 - Motor/Load Ratings
Terminals 1/L1, 3/L2, 5/L3, 2/T1, 4/T2, 6/T3
Rated Insulation Voltage (U
i
) 690V AC
Rated Operating Voltage (U
e
)
IEC:
UL: 690V AC
600V AC
Rated Impulse Voltage (U
imp
) 6 kV
Rated Operating Current (I
e
) See Catalog Number Explanation
Rated Frequency 45...65 Hz ➊
Short Circuit Ratings See Short-Circuit Ratings on page 41
Number of Poles 3
Application Single-phase or Three-phase
Table 344 - Power Supply Ratings
Rated Supply Voltage (U
s
) 24V DC 120V AC 240V AC
Operating Range 11…30V DC 85…132V AC 159…265V AC
Maximum Inrush Current 3 A
Maximum Power Consumption
E300:
E300 with expansion:
6 W
8 W
Maximum Power Interruption Time
V
min
:
V
max
:
5 ms
5 ms 10 ms
10 ms 10 ms
10 ms
Table 345 - Output Relay Ratings (Control Module and Expansion Digital Module)
Terminals
Relay 0:
Relay 1:
Relay 2:
R03/R04
R13/R14
R23/R24
Type of Contacts
Form A
SPST - NO
Rated Thermal Current (I
the
) 5 A
Rated Insulation Voltage (U
i
) 300V AC
Rated Operating Voltage (U
e
) 250V AC
Rated Operating Current (I
e
)
3 A (@120V AC), 1.5 A (@240V AC)
0.25 A (@110V DC), 0.1 A (@220V DC)
Minimum Operating Current 10 mA @ 5V DC
Rating Designation B300
