346 Rockwell Automation Publication 193-UM015B-EN-P - November 2013
Appendix B Parameter List
Device Setup
(continued
) 191 WarningEnableP Bitmask used to enable/disable
power based warnings UINT 2 1 Bit0= UnderKWWarning
Bit1= OverKWWarning
Bit2= UnderKVARConWarn
Bit3= OverKVARConWarn
Bit4= UnderKVARGenWarn
Bit5= OverKVARGenWarn
Bit6= UnderKVAWarning
Bit7= OverKVAWarning
Bit8= UnderPFLagWarn
Bit9= OverPFLagWarn
Bit10= UnderPFLeadWarn
Bit11= OverPFLeadWarn 0
192 WarningEnableC Bitmask used to enable/disable
control based warnings UINT 2 1 Bit0= Reserved
Bit1= PTCWarning
Bit2= DLXWarning
Bit3= Reserved
Bit4= Reserved
Bit5= Reserved
Bit6= Reserved
Bit7= ConfigWarning
Bit8= OptionMatchWarn
Bit9= DLXFBTimeoutWarn
Bit10= ExpansionBusWarn
Bit11= PMNumberOfStarts
Bit12= PMOperatingHour 0
193 WarningEnableA Bitmask used to enable/disable
analog based warnings UINT 2 1 Bit0= InAnMod1Ch00Warn
Bit1= InAnMod1Ch01Warn
Bit2= InAnMod1Ch02Warn
Bit3= InAnMod2Ch00Warn
Bit4= InAnMod2Ch01Warn
Bit5= InAnMod2Ch02Warn
Bit6= InAnMod3Ch00Warn
Bit7= InAnMod3Ch01Warn
Bit8= InAnMod3Ch02Warn
Bit9= InAnMod4Ch00Warn
Bit10= InAnMod4Ch01Warn
Bit11= InAnMod4Ch02Warn 0
194 Reserved
195 SetOperatingMode Logic personality Selection USINT 1 1 2 54 2
196 InPt00Assignment Assignment for Input Point 00
function USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm 0
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
