Rockwell Automation Publication 193-UM015B-EN-P - June 2014 405
EtherNet/IP Information Appendix C
Wall Clock Time Object — CLASS CODE 0x008B
The following class attributes are supported:
Table 419 - Wall Clock Time Object Class Attributes
One instance is supported:
Table 420 - Wall Clock Time Object Instance Attributes
15 REAL L1 to N Voltage Attribute 15 Value
16 REAL L2 to N Voltage Attribute 16 Value
17 REAL L3 to N Voltage Attribute 17 Value
18 REAL Avg Voltage L to N Attribute 18 Value
19 REAL L1 to L2 Voltage Attribute 19 Value
20 REAL L2 to L3 Voltage Attribute 20 Value
21 REAL L3 to L1 Voltage Attribute 21 Value
22 REAL Avg Voltage Lto N Attribute 22 Value
23 REAL Percent Voltage Unbalance Attribute 23 Value
24 REAL L1 Real Power Attribute 24 Value
25 REAL L2 Real Power Attribute 25 Value
26 REAL L3 Real Power Attribute 26 Value
27 REAL Total Real Power Attribute 27 Value
28 REAL L1 Reactive Power Attribute 28 Value
29 REAL L2 Reactive Power Attribute 29 Value
30 REAL L3 Reactive Power Attribute 30 Value
31 REAL Total Reactive Power Attribute 31 Value
32 REAL L1 Apparent Power Attribute 32 Value
33 REAL L2 Apparent Power Attribute 33 Value
34 REAL L3 Apparent Power Attribute 34 Value
35 REAL Total Apparent Power Attribute 35 Value
36 REAL L1 True Power Factor Attribute 36 Value
37 REAL L2 True Power Factor Attribute 37 Value
38 REAL L3 True Power Factor Attribute 38 Value
39 REAL Three Phase True Power Factor Attribute 39 Value
40 UINT Phase Rotation Attribute 40 Value
41
STRUCT of UINT
Padded EPATH
Associated Energy Object Path Attribute 41 Value
Attribute ID Access Rule Name Data Type Value
1 Get Object Revision UINT 3
2 Get Number of Instances UINT 1
Attribute ID Data Type Name Value
Attribute ID Access Rule Name Data Type Value
2 Set Time Zone UINT
Time zone in which Current value is being used (Never been
used)
3 Set / SSV Offset from CSV LINT
64-bit offset value in μS that when added to the CST value yields
the Current_UTC_Value
4 Set Local Time Adjustment WORD Set of flags for specific local time adjustments (Never been used)
