Metering and Diagnostics Chapter 7
Device Status 1
Device Status 1 (Parameter 21) reports the specific features of the E300
Electronic Overload Relay Control and Sensing Modules, it reports which
Expansion Digital Modules Analog Modules are present on the E300 Electronic
Overload Relay Expansion Bus.
Table 227 - Device Status 1 (Parameter 21)
Firmware Revision Number
Firmware Revision Number (Parameter 22) reports the firmware revision
number of the E300 Electronic Overload Relay system.
Table 228 - Firmware Revision Number (Parameter 22)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Function
X
24V DC Control Module Present
X
120V AC Control Module Present
X
240V AC Control Module Present
X
0.5…30 A Sensing Module Present
X
6…60 A Sensing Module Present
X
10…100 A Sensing Module Present
X
20…2000 A Sensing Module Present
X
Digital Module 1 Present
X
Digital Module 2 Present
X
Digital Module 3 Present
X
Digital Module 4 Present
X
Analog Module 1 Present
X
Analog Module 2 Present
X
Analog Module 3 Present
X
Analog Module 4 Present
Reserved
Default Value
0.000
Minimum Value
0.000
Maximum Value
65.535
Parameter Type
UINT
Size (Bytes)
2
Scaling Factor
1000
Units
