Rockwell Automation Publication 193-UM015B-EN-P - November 2013

Appendix B Parameter List

Options Setup
(Continued)

224

OperStationType

Select Operator Station Type

USINT

1

1

0= IgnoreType
1= NoStation
2= ControlStation
3= DiagStation

0

225

DigitalMod1Type

Select Digital I/O Expansion
Module 1 Type

USINT

1

1

0= IgnoreType
1=NoModule
2=4In2Out24VDC
3=4In2Out120VAC
4=4In2Out240VAC

0

226

DigitalMod2Type

Select Digital I/O Expansion
Module 2 Type

USINT

1

1

0= IgnoreType
1=NoModule
2=4In2Out24VDC
3=4In2Out120VAC
4=4In2Out240VAC

0

227

DigitalMod3Type

Select Digital I/O Expansion
Module 3 Type

USINT

1

1

0= IgnoreType
1=NoModule
2=4In2Out24VDC
3=4In2Out120VAC
4=4In2Out240VAC

0

228

DigitalMod4Type

Select Digital I/O Expansion
Module 4 Type

USINT

1

1

0= IgnoreType
1=NoModule
2=4In2Out24VDC
3=4In2Out120VAC
4=4In2Out240VAC

0

229

AnalogMod1Type

Select Analog I/O Expansion
Module 1 Type

USINT

1

1

0=IgnoreType
1=NoModule
2=3In1OutAnalog

0

230

AnalogMod2Type

Select Analog I/O Expansion
Module 2 Type

USINT

1

1

0=IgnoreType
1=NoModule
2=3In1OutAnalog

0

231

AnalogMod3Type

Select Analog I/O Expansion
Module 3 Type

USINT

1

1

0=IgnoreType
1=NoModule
2=3In1OutAnalog

0

232

AnalogMod4Type

Select Analog I/O Expansion
Module 4 Type

USINT

1

1

0=IgnoreType
1=NoModule
2=3In1OutAnalog

0

233

MismatchAction

Select Mismatched Module
Actions 0=warning 1= fault

UINT

1

1

Bit0= ControlModule
Bit1= SensingModule
Bit2= CommsModule
Bit3= OperatorStation
Bit4= DigitalModule1
Bit5= DigitalModule2
Bit6= DigitalModule3
Bit7= DigitalModule4
Bit8= AnalogModule1
Bit9= AnalogModule1
Bit10= AnalogModule1
Bit11= AnalogModule1

0

234

Reserved

235

Reserved

236

Reserved

237

Reserved

238

Reserved

Group

Param

No.

Parameter Name

Description

Type

Data Size

(bytes)

Scale

Factor

Min

Max

Default Units
