Operator Station Type (Parameter 224)
The E300 Electronic Overload Relay offers two different types of operator
stations. Place the value of the expected operator station into Parameter 224. A
value of (0) disables the Option Match feature for the operator station. A value of
(1),
“No Operator Station”, makes the operator station not available to the
Expansion Bus and prevents a user from connecting an operator station to the
E300 Electronic Overload Relay system.
Table 28 - Operator Station Type (Parameter 224)
Digital I/O Expansion Module 1 Type (Parameter 225)
The E300 Electronic Overload Relay supports up to four additional Digital I/O
expansion modules. This parameter configures the Option Match feature for the
Digital I/O expansion module at Digital Module Address 1. There are three
different types of Digital I/O expansion modules. Place the value of the expected
Digital I/O expansion module at Digital Module Address 1 into Parameter 225.
A value of (0) disables the Option Match feature for this Digital I/O expansion
module. A value of (1),
“No Digital I/O Expansion Module at Digital Module
Address 1”, makes the Digital I/O expansion module at Digital Module Address 1
not available to the Expansion Bus and prevents a user from connecting a Digital
I/O expansion module at Digital Module Address 1 to the E300 Electronic
Overload Relay system.
Table 29 - Digital I/O Expansion Module 1 Type (Parameter 225)
Code Description Operator Station Cat. No.
0 Ignore —
1 No Operator Station (Operator Station Not Available) —
2 Control Station 193-EOS-SCS
3 Diagnostic Station with LCD 193-EOS-SDS
Code Description Digital I/O Expansion Module Cat. No.
0 Ignore —
1
No Digital I/O Expansion Module (Digital I/O Expansion
Module Not Available)
—
2 4 Inputs, 24V DC / 2 Relay Outputs 193-EXP-DIO-42-24D
3 4 Inputs, 110-120V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-120
4 4 Inputs, 220-240V AC 50/60Hz / 2 Relay Outputs 193-EXP-DIO-42-240
