Rockwell Automation Publication 193-UM015B-EN-P - November 2013 357
Parameter List Appendix B
Power Setup
(Continued)
407 OVATripDelay Over Total Apparent Power Trip
Delay USINT 1 10 1 250 10 Sec
408 OVATripLevel Over Total Apparent Power Trip
Level DINT 4 1000 0 2000000000 0 kVA
409 OVAWarningLevel Over Total Apparent Power
Warning Level DINT 4 1000 0 2000000000 0 kVA
410 UPFLagInhibTime Under Total Power Factor Lagging
(-PF) Inhibit Time USINT 1 1 0 250 10 Sec
411 UPFLagTripDelay Under Total Power Factor Lagging
(-PF) Trip Delay USINT 1 10 1 250 10 Sec
412 UPFLagTripLevel Under Total Power Factor Lagging
(-PF) Trip Level SINT 1 1 -100 0 -90 %
413 UPFLagWarnLevel Under Total Power Factor Lagging
(-PF) Warning Level SINT 1 1 -100 0 -95 %
414 OPFLagInhibTime Over Total Power Factor Lagging
(-PF) Inhibit Time USINT 1 1 0 250 10 Sec
415 OPFLagTripDelay Over Total Power Factor Lagging
(-PF) Trip Delay USINT 1 10 1 250 10 Sec
416 OPFLagTripLevel Over Total Power Factor Lagging
(-PF) Trip Level SINT 1 1 -100 0 -95 %
417 OPFLagWarnLevel Over Total Power Factor Lagging
(-PF) Warning Level SINT 1 1 -100 0 -90 %
418 UPFLeadInhibTime Under Total Power Factor Leading
(+PF) Inhibit Time USINT 1 1 0 250 10 Sec
419 UPFLeadTripDelay Under Total Power Factor Leading
(+PF) Trip Delay USINT 1 10 1 250 10 Sec
420 UPFLeadTripLevel Under Total Power Factor Leading
(+PF) Trip Level USINT 1 1 0 100 90 %
421 UPFLeadWarnLevel Under Total Power Factor Leading
(+PF) Warning Level USINT 1 1 0 100 95 %
422 OPFLeadInhibTime Over Total Power Factor Leading
(+PF) Inhibit Time USINT 1 1 0 250 10 Sec
423 OPFLeadTripDelay Over Total Power Factor Leading
(+PF) Trip Delay USINT 1 10 1 250 10 Sec
424 OPFLeadTripLevel Over Total Power Factor Leading
(+PF) Trip Level USINT 1 1 0 100 95 %
425 OPFLeadWarnLevel Over Total Power Factor Leading
(+PF) Warning Level USINT 1 1 0 100 90 %
426 DemandPeriod The number of minutes in a
specific demand period USINT 1 1 1 255 15 Min
427 NumberOfPeriods The number of periods to average
for the demand calculation USINT 1 1 1 15 1
Diagnostic
Display Setup 428 Screen1Param1 Parameter to display on Operator
Station Startup screen 1 line 1 UINT 2 1 0 560 1
429 Screen1Param2 Parameter to display on Operator
Station Startup screen 1 line 2 UINT 2 1 0 560 50
430 Screen2Param1 Parameter to display on Operator
Station Startup screen 2 line 1 UINT 2 1 0 560 2
431 Screen2Param2 Parameter to display on Operator
Station Startup screen 2 line 2 UINT 2 1 0 560 3
432 Screen3Param1 Parameter to display on Operator
Station Startup screen 3 line 1 UINT 2 1 0 560 51
433 Screen3Param2 Parameter to display on Operator
Station Startup screen 3 line 2 UINT 2 1 0 560 52
434 Screen4Param1 Parameter to display on Operator
Station Startup screen 4 line 1 UINT 2 1 0 560 38
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
