Chapter 5 Protective Trip and Warning Functions
Phase Loss Trip
The E300 Electronic Overload Relay will trip with a phase loss indication if:
• No trip currently exists
• Phase Loss Protection is enabled
• Current is Present
• Phase Loss Inhibit Time has expired
• Current Imbalance is equal to or greater than 100% for a time period
greater than the programmed Phase Loss Trip Delay
If the E300 Electronic Overload Relay trips on a phase loss, the:
• TRIP/WARN LED status indicator will flash a red short-2 blink pattern
• Bit 1 in Current Trip Status (Parameter 4) will set to 1
• Bit 0 of Device Status 0 (Parameter 20) will set to 1
• Any relay outputs configured as a Trip Relay will open
• Any relay outputs configured as a Control Relay will open
• Any relay outputs configured as a Trip Alarm will close
• Any relay outputs configured as a Normal Relay will be placed in their
Protection Fault state (if so programmed)
IMPORTANT The phase loss inhibit timer starts after the maximum phase of load current
transitions from 0 A to 30% of the device’s minimum FLA Setting. The E300
Electronic Overload Relay does not begin monitoring for a phase loss condition
until the Phase Loss Inhibit Time expires.
IMPORTANT The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
• Output PT00 Protection Fault Action (Parameter 304)
• Output PT00 Protection Fault Value (Parameter 305)
• Output PT01 Protection Fault Action (Parameter 310)
• Output PT01 Protection Fault Value (Parameter 311)
• Output PT02 Protection Fault Action (Parameter 316)
• Output PT02 Protection Fault Value (Parameter 317)
• Output Digital Module 1 Protection Fault Action (Parameter 322)
• Output Digital Module 1 Protection Fault Value (Parameter 323)
• Output Digital Module 2 Protection Fault Action (Parameter 328)
• Output Digital Module 2 Protection Fault Value (Parameter 329)
• Output Digital Module 3 Protection Fault Action (Parameter 334)
• Output Digital Module 3 Protection Fault Value (Parameter 335)
• Output Digital Module 4 Protection Fault Action (Parameter 340)
• Output Digital Module 4 Protection Fault Value (Parameter 342)
