262 Rockwell Automation Publication 193-UM015B-EN-P - June 2014
Chapter 7 Metering and Diagnostics
Table 304 - kVARh Net x 10E-3 (Parameter 99)
kVAh 10
9
kVAh 10
9
(Parameter 100) reports a component of total apparent energy
(kVAh). Multiply this value by 10
9
and add to the other kVAh parameters.
Represents XXX, 000,000,000.000 kVAh
Table 305 - kVAh x 10E9 (Parameter 100)
kVAh 10
6
kVAh 10
6
(Parameter 101) reports a component of total apparent energy
(kVAh). Multiply this value by 10
6
and add to the other kVAh parameters.
Represents 000,XXX,000,000.000 kVAh
Table 306 - kVAh x 10E6 (Parameter 101)
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
