Rockwell Automation Publication 193-UM015B-EN-P - November 2013
335
Parameter List Appendix B
Device Monitor
(continued)
21
DeviceStatus1
Device Status bits
UINT
2
1
Bit0= 24VoltControl
Bit1= 120VoltControl
Bit2= 240VoltControl
Bit3= CurrentSense30A
Bit4= CurrentSense60A
Bit5= CurrentSense100A
Bit6= CurrentSense200A
Bit7= DigitalModule1
Bit8= DigitalModule2
Bit9= DigitalModule3
Bit10= DigitalModule4
Bit11= AnalogModule1
Bit12= AnalogModule2
Bit13= AnalogModule3
Bit14= AnalogModule4
0
22
Firmware
Firmware Revision Number
UINT
2
1000
0
65535
1001
23
ControlModuleID
Control Module Type Detected
USINT
1
1
0= Unknown
1= 6In3Out24VDC
2= 4In3Out120VAC
3= 4In3Out240VAC
4= 4In2OutGFPTC24V
5= 2In2OutGFPTC120V
6= 2In2OutGFPTC240V
0
24
SensingModuleID
Sensing Module Types Detected
USINT
1
1
0= Unknown
1= VIGPt5to30Amp
2= VIG6to60Amp
3= VIG10to100Amp
4= VIG20to200Amp
5= IGPt5to30Amp
6= IG6to60Amp
7= IG10to100Amp
8= IG20to200Amp
9= IPt5to30Amp
10= I6to60Amp
11= I10to100Amp
12= I20to200Amp
0
25
OperStationID
Operator Station Types Detected
USINT
1
1
0= Unknown
1= NoStation
2= ControlStation
3= DiagStation
0
26
DigitalModuleID
Expansion Digital Module Types
Detected
UINT
2
1
Bit0= DigitalMod1[0]
Bit1= DigitalMod1[1]
Bit2= DigitalMod1[2]
Bit3= DigitalMod2[0]
Bit4= DigitalMod2[1]
Bit5= DigitalMod2[2]
Bit6= DigitalMod3[0]
Bit7= DigitalMod3[1]
Bit8= DigitalMod3[2]
Bit9= DigitalMod4[0]
Bit10= DigitalMod4[1]
Bit11= DigitalMod4[2]
0
Group
Param
No.
Parameter Name
Description
Type
Data Size
(bytes)
Scale
Factor
Min
Max
Default Units
