Rockwell Automation Publication 193-UM015B-EN-P - November 2013 347
Parameter List Appendix B
Device Setup
(continued
197 InPt01Assignment Assignment for Input Point 01
function USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm 0
198 InPt02Assignment Assignment for Input Point 02
function USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm 0
199 InPt03Assignment Assignment for Input Point 03
function USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm 0
200 InPt04Assignment Assignment for Input Point 04
function USINT 1 1 0=Normal
1=TripReset
2=RemoteTrip
3=ActivateFLA2
4=ForceSnapshot
5=EmergencyStart
6=TestMode
7=L1LossArm
8=L2LossArm
9=L3LossArm
10=L1L2LossArm
11=L2L3LossArm
12=L1L3LossArm
13=L1L2L3LossArm 0
Group
Param
No.
Parameter Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
